| Wavelength: | 375nm, 405nm, 445nm, 473nm, 488nm |
| Output Power (single transverse mode): | 1mW - 180mW |
| Output Power (multi transversal mode): | Up to 500mW (at selected wavelengths) |
| Spatial Mode: | TEM00 or Higher Order Modes (power dependent) |
| M2 (for single transversal mode): | <1.1 |
| Polarization (customer specified direction): | >100:1 |
| Beam Roundness: | >95% |
| Beam Diameter at Exit Aperture @ 1/e2: | >0.1mm |
| Linewidth (FWHM): | >0.1nm |
| Beam Divergence (for single transversal mode): | <1mrad |
| Beam Pointing Stability: | <0.005mrad |
Long-term Power Stability
(10 hours of continuous operation), Typical: | +/-0.5% |
| Noise Level to 100MHz (rms): | <0.1% |
| External Modulation Option: | Available |
| Warm-up Time: | <1 minute |
| Operating Volatage: | 5V DC +/- 10% |
| Maximum Power Consumption | typ 1.5W; max 3W |
| Operating Temperature: | 10C - 40C |
| Storage Temperature: | -20C - +70C |
| Laser Head Dimensions (LxWxH): | 100mm x 40mm x 20mm |
| Laser Controller: | Inbuilt |
| Cable Length: | 750mm (other options available) |
| Laser Head Weight: | 90g |
| Cable Weight: | 40g |
